WOHLHAUPTER - Neutral Cut, 28mm Min Bore Diam, Size F101 Modular Boring Cutting Unit Head - 3.307" Max Bore Depth, Through Coolant, Compatible with CCMT06
Item #: 66293416
Brand: WOHLHAUPTER
Model #: 502056
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| System Size | F101 |
| Series Name | Digibore |
| Minimum Bore Diameter (mm) | 28.00 |
| Minimum Bore Diameter (Decimal Inch) | 1.1024 |
| Cutting Direction | Neutral |
| Maximum Bore Depth (mm) | 84.00 |
| Maximum Bore Depth (Decimal Inch) | 3.3070 |
| Insert Style | CCMT06 |
| Head Length/Projection (mm) | 11.98 |
| Head Length/Projection (Decimal Inch) | 0.4720 |
| Insert Holding Method | Screw |
| Through Coolant | Through Coolant |
| Head Diameter Excluding Insert (mm) | 65.00 |
| Head Diameter Excluding Insert (Decimal Inch) | 2.5590 |
| Complete Insert Compatibility | CC..06.. |
