Associated Spring Raymond - 7.3mm OD, 1mm Wire, 30.5mm Free Length, Compression Spring - 18.6 Lb Spring Rating, 28.47 N Max Work Load, Stainless Steel
Item #: 65803868
Brand: Associated Spring Raymond
Model #: D21930
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 7.29 |
| Outside Diameter (Decimal Inch) | 0.2870 |
| Free Length (mm) | 30.51 |
| Free Length (Decimal Inch) | 1.2010 |
| Spring Rate Pounds per Inch (Pounds) | 18.6000 |
| Maximum Work Load (N) | 28.46999931 |
| Solid Height (mm) | 14-1/2 |
| Solid Height (Decimal Inch) | 0.5710 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.99 |
| Wire Size (Decimal Inch) | 0.0390 |
