M.A. Ford - 16mm, 4 Flute, Single End, Solid Carbide, 0.3mm Corner Radius End Mill - 150mm OAL, 35/38° Helix, Right Hand Flute, 24mm LOC, Right Hand Cut,
Item #: 65777807
Brand: M.A. Ford
Model #: 15862900R012N3A
Exact Tooling IR#: 04
Features and Benefits
Solid carbide provides better rigidity than high speed steel. It is extremely heat resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
ALtima 52 is specially designed for milling hardened steels 52 Rc and above. It is manufactured to allow for dry machining. Altima 52 is a proprietary coating exclusive to M.A. Ford Mfg. Co., Inc.
| Product Specifications | |
|---|---|
| Mill Diameter (mm) | 16.00 |
| Mill Diameter (Decimal Inch) | 0.6299 |
| End Type | Corner Radius |
| Corner Radius (mm) | 0.300 |
| Corner Radius (Decimal Inch) | 0.0120 |
| Number of Flutes | 4 |
| Material | Solid Carbide |
| Finish/Coating | ALtima 52 |
| Length of Cut (mm) | 24.00 |
| Length of Cut (Decimal Inch) | 0.9449 |
| Shank Diameter (mm) | 16.00 |
| Overall Length (mm) | 150.00 |
| Flute Type | Spiral |
| Cutting Direction | Right Hand |
| Helix Angle | 35/38 |
| Neck Diameter (mm) | 15.20 |
| Single or Double End | Single |
| Centercutting | Yes |
| Flute Direction | Right Hand |
| Extended Reach | Yes |
| Series/List | 158 |
