Corner Radius End Mill: 3/4″ Dia, 1″ LOC, 0.06″ Radius, 7 Flutes, Solid Carbide 4″ OAL, 3/4″ Shank Dia, 38 ° Helix, ALtima Blaze Coated, Corner Radius End, Series 180
Item #: 65773806
Brand: M.A. Ford?
Model #: 18075006B
Product Specifications
| Mill Diameter (Decimal Inch) | 0.7500 |
| Mill Diameter (Inch) | 3/4 |
| Length of Cut (Inch) | 1 |
| Corner Radius (Decimal Inch) | 0.0600 |
| Number Of Flutes | 7 |
| End Mill Material | Solid Carbide |
| Extended Reach | No |
| End Type | Corner Radius |
| Flute Type | Spiral |
| Helix Angle | 38 |
| Shank Type | Straight-Cylindrical |
| Centercutting | No |
| Variable Index | Yes |
| Variable Helix | No |
| Material Removal Type | Finishing |
| Shank Diameter (Inch) | 3/4 |
| Overall Length (Inch) | 4 |
| Overall Length (Decimal Inch) | 4.0000 |
| Maximum Helix Angle | 38.00 |
| Mill Diameter Tolerance | +0.000000 to -0.003000 in |
| Primary Workpiece Material | Stainless Steel; Steel; Super Alloys & Titanium |
| Primary Workpiece Material Code | P; S; M |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Series | 180 |
| Single Or Double End | Single |
| Coating/Finish | ALtima Blaze |
| Length Of Cut (Decimal Inch - 4 Decimals) | 1.0000 |
