HALDER - 9mm Body Length x 8mm Body Diam, 10 N Init to 20.4 N Final End Force, Thermoplastic Press Fit Ball Plunger - 6.5mm Ball Diam, 1.9mm Max Ball Reach, 0.1mm Tolerance, 1mm Flange Thickness
Item #: 64829633
Brand: HALDER
Model #: 22080.0408
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (mm) | 8.00 |
| Body Length (mm) | 9.00 |
| Body Material | Thermoplastic |
| Ball Material | Stainless Steel |
| Flange | Yes |
| Maximum Ball Reach (mm) | 1.90 |
| Initial End Force (N) | 10.00 |
| Final End Force (N) | 20.40 |
| Length Under Flange (mm) | 8.00 |
| Flange Diameter (mm) | 8.50 |
| Flange Thickness (mm) | 1.00 |
| Ball Diameter (mm) | 6.50 |
| Finish/Coating | Matte |
| Tolerance (mm) | +0.10 |
| Locking Element | No |
