Kyocera - 5 Inserts, 2" Cut Diam, 0.417" Arbor Diam, 0.394" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 1.575" High, BDMT 11T3 Insert Compatibility, Through Coolant
Item #: 64327653
Brand: Kyocera
Model #: 8607051
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 2.0000 |
| Arbor Hole Diameter (Decimal Inch) | 0.4170 |
| Lead Angle | 0 |
| Overall Height (Decimal Inch) | 1.5750 |
| Insert Compatibility | BDMT 11T3 |
| Through Coolant | Yes |
| Maximum Depth of Cut (Decimal Inch) | 0.3940 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 5 |
| Insert Holding Method | Screw |
| Cutter Style | MEC |
| Number of Flutes | 5 |
| Cutting Rake Angle | -7 |
| Rake | Negative |
| Keyway Width (Decimal Inch) | 0.3120 |
| Keyway Depth (Decimal Inch) | 0.1880 |
| Maximum RPM | 22300 |
| Counterbore Diameter (Decimal Inch) | 0.6460 |
| Complete Insert Compatibility | BDMT 11T302ER-JS; BDMT 11T302ER-JT; BDMT 11T302FR; BDMT 11T302FR-JA; BDMT 11T304ER-JS; BDMT 11T304ER-JT; BDMT 11T304FR; BDMT 11T304FR-JA; BDMT 11T308ER-JS; BDMT 11T308ER-JT; BDMT 11T308FR-JA; BDMT 11T312ER-JT; BDMT 11T316ER-JT; BDMT 11T320ER-JT; BDMT 11T3 |
