Vlier - 3/8-16, 0.187" Ball Diam, 0.625" Body Length, 0.053" Max Ball Reach, Threaded Ball Plunger - Delrin Body, Nylon Ball, 5 Lb Initial End Force, 10 Lb Final End Force
Item #: 62123302
Brand: Vlier
Model #: ND58
Exact Tooling IR#: 04
Features and Benefits
Delrin is a thermoplastic resin that combines the properties of metal and plastic. It offers strength, hardness, dimensional stability, fuel and abrasion resistance as well as has low friction.
Nylon balls are ideal for applications where products or components are made mostly or entirely of plastic. They are lightweight, highly durable and non-marring.
| Product Specifications | |
|---|---|
| Thread Size | 3/8-16 |
| Body Length (Decimal Inch) | 0.6250 |
| Body Material | Delrin |
| Ball Material | Nylon |
| Initial End Force (Lb.) | 5.00 |
| Final End Force (Lb.) | 10.00 |
| Locking Element | No |
| Ball Diameter (Decimal Inch) | 0.1870 |
| Maximum Ball Reach (Decimal Inch) | 0.0530 |
