Associated Spring Raymond - 5.33mm OD, 0.66mm Wire, 7.87mm Free Length, Compression Spring - 33.9 Lb Spring Rating, 18.42 N Max Work Load, Music Wire
Item #: 61428728
Brand: Associated Spring Raymond
Model #: C02100260310M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 5.33 |
Outside Diameter (Decimal Inch) | 0.2100 |
Free Length (mm) | 7.87 |
Free Length (Decimal Inch) | 0.3100 |
Spring Rate Pounds per Inch (Pounds) | 33.9000 |
Maximum Work Load (N) | 18.42000008 |
Solid Height (mm) | 4.04 |
Solid Height (Decimal Inch) | 0.1590 |
Material | Music Wire |
Wire Size (mm) | 0.66 |
Wire Size (Decimal Inch) | 0.0260 |
