Associated Spring Raymond - 5.33mm OD, 0.46mm Wire, 11.18mm Free Length, Compression Spring - 5.8 Lb Spring Rating, 6.67 N Max Work Load, Music Wire
Item #: 61428264
Brand: Associated Spring Raymond
Model #: C02100180440M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 5.33 |
| Outside Diameter (Decimal Inch) | 0.2100 |
| Free Length (mm) | 11.18 |
| Free Length (Decimal Inch) | 0.4400 |
| Spring Rate Pounds per Inch (Pounds) | 5.8000 |
| Maximum Work Load (N) | 6.67000008 |
| Solid Height (mm) | 3.05 |
| Solid Height (Decimal Inch) | 0.1200 |
| Material | Music Wire |
| Wire Size (mm) | 0.46 |
| Wire Size (Decimal Inch) | 0.0180 |
