Associated Spring Raymond - 4.57mm OD, 0.81mm Wire, 1-1/4" Free Length, Compression Spring - 22.8 Lb Spring Rating, 39.28 N Max Work Load, Music Wire
Item #: 61427704
Brand: Associated Spring Raymond
Model #: C01800321250M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Free Length (mm) | 31-3/4 |
Free Length (Decimal Inch) | 1-1/4 |
Spring Rate Pounds per Inch (Pounds) | 22.8000 |
Maximum Work Load (N) | 39.27999878 |
Solid Height (mm) | 19 |
Solid Height (Decimal Inch) | 0.7480 |
Material | Music Wire |
Wire Size (mm) | 0.81 |
Wire Size (Decimal Inch) | 0.0320 |
