Associated Spring Raymond - 4.57mm OD, 0.81mm Wire, 28.45mm Free Length, Compression Spring - 25.6 Lb Spring Rating, 39.28 N Max Work Load, Music Wire
Item #: 61427613
Brand: Associated Spring Raymond
Model #: C01800321120M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 28.45 |
| Free Length (Decimal Inch) | 1.1200 |
| Spring Rate Pounds per Inch (Pounds) | 25.6000 |
| Maximum Work Load (N) | 39.27999878 |
| Solid Height (mm) | 17.20 |
| Solid Height (Decimal Inch) | 0.6770 |
| Material | Music Wire |
| Wire Size (mm) | 0.81 |
| Wire Size (Decimal Inch) | 0.0320 |
