Associated Spring Raymond - 4.57mm OD, 0.74mm Wire, 50.8mm Free Length, Compression Spring - 7.7 Lb Spring Rating, 17.93 N Max Work Load, Stainless Steel
Item #: 61427415
Brand: Associated Spring Raymond
Model #: C01800292000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 50.80 |
| Free Length (Decimal Inch) | 2 |
| Spring Rate Pounds per Inch (Pounds) | 7.7000 |
| Maximum Work Load (N) | 17.93000031 |
| Solid Height (mm) | 25.83 |
| Solid Height (Decimal Inch) | 1.0170 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.74 |
| Wire Size (Decimal Inch) | 0.0290 |
