Associated Spring Raymond - 4.57mm OD, 0.66mm Wire, 17.53mm Free Length, Compression Spring - 18.8 Lb Spring Rating, 22.38 N Max Work Load, Music Wire
Item #: 61426748
Brand: Associated Spring Raymond
Model #: C01800260690M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 17.53 |
| Free Length (Decimal Inch) | 0.6900 |
| Spring Rate Pounds per Inch (Pounds) | 18.8000 |
| Maximum Work Load (N) | 22.37999916 |
| Solid Height (mm) | 8.23 |
| Solid Height (Decimal Inch) | 0.3240 |
| Material | Music Wire |
| Wire Size (mm) | 0.66 |
| Wire Size (Decimal Inch) | 0.0260 |
