Associated Spring Raymond - 4.57mm OD, 0.56mm Wire, 1/2" Free Length, Compression Spring - 14.2 Lb Spring Rating, 13.92 N Max Work Load, Music Wire
Item #: 61426060
Brand: Associated Spring Raymond
Model #: C01800220500M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 12.70 |
| Free Length (Decimal Inch) | 1/2 |
| Spring Rate Pounds per Inch (Pounds) | 14.2000 |
| Maximum Work Load (N) | 13.92000008 |
| Solid Height (mm) | 4.88 |
| Solid Height (Decimal Inch) | 0.1920 |
| Material | Music Wire |
| Wire Size (mm) | 0.56 |
| Wire Size (Decimal Inch) | 0.0220 |
