Associated Spring Raymond - 4.57mm OD, 0.46mm Wire, 35.05mm Free Length, Compression Spring - 2.3 Lb Spring Rating, 7.83 N Max Work Load, Music Wire
Item #: 61425716
Brand: Associated Spring Raymond
Model #: C01800181380M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Free Length (mm) | 35.05 |
Free Length (Decimal Inch) | 1.3800 |
Spring Rate Pounds per Inch (Pounds) | 2.3000 |
Maximum Work Load (N) | 7.82999992 |
Solid Height (mm) | 8.38 |
Solid Height (Decimal Inch) | 0.3300 |
Material | Music Wire |
Wire Size (mm) | 0.46 |
Wire Size (Decimal Inch) | 0.0180 |
