Associated Spring Raymond - 4.57mm OD, 0.41mm Wire, 11.18mm Free Length, Compression Spring - 4.9 Lb Spring Rating, 5.56 N Max Work Load, Music Wire
Item #: 61425179
Brand: Associated Spring Raymond
Model #: C01800160440M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 11.18 |
| Free Length (Decimal Inch) | 0.4400 |
| Spring Rate Pounds per Inch (Pounds) | 4.9000 |
| Maximum Work Load (N) | 5.55999994 |
| Solid Height (mm) | 2.84 |
| Solid Height (Decimal Inch) | 0.1120 |
| Material | Music Wire |
| Wire Size (mm) | 0.41 |
| Wire Size (Decimal Inch) | 0.0160 |
