Associated Spring Raymond - 4.57mm OD, 0.36mm Wire, 3/4" Free Length, Compression Spring - 1.9 Lb Spring Rating, 3.74 N Max Work Load, Music Wire
Item #: 61424933
Brand: Associated Spring Raymond
Model #: C01800140750M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 1.9000 |
| Maximum Work Load (N) | 3.74000001 |
| Solid Height (mm) | 3.30 |
| Solid Height (Decimal Inch) | 0.1300 |
| Material | Music Wire |
| Wire Size (mm) | 0.36 |
| Wire Size (Decimal Inch) | 0.0140 |
