Associated Spring Raymond - 4.57mm OD, 0.3mm Wire, 14.22mm Free Length, Compression Spring - 1.3 Lb Spring Rating, 1.38 N Max Work Load, Stainless Steel
Item #: 61424511
Brand: Associated Spring Raymond
Model #: C01800120560X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 14.22 |
| Free Length (Decimal Inch) | 0.5600 |
| Spring Rate Pounds per Inch (Pounds) | 1.3000 |
| Maximum Work Load (N) | 1.38000000 |
| Solid Height (mm) | 2.16 |
| Solid Height (Decimal Inch) | 0.0850 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.30 |
| Wire Size (Decimal Inch) | 0.0120 |
