Associated Spring Raymond - 3.76mm OD, 0.58mm Wire, 1-1/4" Free Length, Compression Spring - 7.3 Lb Spring Rating, 10.94 N Max Work Load, Stainless Steel
Item #: 61424370
Brand: Associated Spring Raymond
Model #: C01480231250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.76 |
| Outside Diameter (Decimal Inch) | 0.1480 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 7.3000 |
| Maximum Work Load (N) | 10.93999958 |
| Solid Height (mm) | 15.42 |
| Solid Height (Decimal Inch) | 0.6070 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.58 |
| Wire Size (Decimal Inch) | 0.0230 |
