Associated Spring Raymond - 6.1mm OD, 0.56mm Wire, 7.87mm Free Length, Compression Spring - 12.6 Lb Spring Rating, 6.14 N Max Work Load, Stainless Steel
Item #: 61423554
Brand: Associated Spring Raymond
Model #: C02400220310X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 7.87 |
| Free Length (Decimal Inch) | 0.3100 |
| Spring Rate Pounds per Inch (Pounds) | 12.6000 |
| Maximum Work Load (N) | 6.13999987 |
| Solid Height (mm) | 2.87 |
| Solid Height (Decimal Inch) | 0.1130 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.56 |
| Wire Size (Decimal Inch) | 0.0220 |
