Associated Spring Raymond - 6.1mm OD, 0.66mm Wire, 7.87mm Free Length, Compression Spring - 28.7 Lb Spring Rating, 17.13 N Max Work Load, Music Wire
Item #: 61423448
Brand: Associated Spring Raymond
Model #: C02400260310M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 7.87 |
| Free Length (Decimal Inch) | 0.3100 |
| Spring Rate Pounds per Inch (Pounds) | 28.7000 |
| Maximum Work Load (N) | 17.12999916 |
| Solid Height (mm) | 3.51 |
| Solid Height (Decimal Inch) | 0.1380 |
| Material | Music Wire |
| Wire Size (mm) | 0.66 |
| Wire Size (Decimal Inch) | 0.0260 |
