Associated Spring Raymond - 6.1mm OD, 1.02mm Wire, 14.22mm Free Length, Compression Spring - 62.2 Lb Spring Rating, 35.14 N Max Work Load, Stainless Steel
Item #: 61422960
Brand: Associated Spring Raymond
Model #: C02400400560X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 6.10 |
| Outside Diameter (Decimal Inch) | 0.2400 |
| Free Length (mm) | 14.22 |
| Free Length (Decimal Inch) | 0.5600 |
| Spring Rate Pounds per Inch (Pounds) | 62.2000 |
| Maximum Work Load (N) | 35.13999939 |
| Solid Height (mm) | 9.30 |
| Solid Height (Decimal Inch) | 0.3660 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.02 |
| Wire Size (Decimal Inch) | 0.0400 |
