Associated Spring Raymond - 3.76mm OD, 0.53mm Wire, 17.53mm Free Length, Compression Spring - 9.6 Lb Spring Rating, 8.41 N Max Work Load, Stainless Steel
Item #: 61421921
Brand: Associated Spring Raymond
Model #: C01480210690X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.76 |
| Outside Diameter (Decimal Inch) | 0.1480 |
| Free Length (mm) | 17.53 |
| Free Length (Decimal Inch) | 0.6900 |
| Spring Rate Pounds per Inch (Pounds) | 9.6000 |
| Maximum Work Load (N) | 8.40999985 |
| Solid Height (mm) | 7.95 |
| Solid Height (Decimal Inch) | 0.3130 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.53 |
| Wire Size (Decimal Inch) | 0.0210 |
