Associated Spring Raymond - 3.05mm OD, 0.61mm Wire, 1-1/4" Free Length, Compression Spring - 14.91 Lb Spring Rating, 15.66 N Max Work Load, Stainless Steel
Item #: 61421749
Brand: Associated Spring Raymond
Model #: C01200241250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 14.9100 |
| Maximum Work Load (N) | 15.65999985 |
| Solid Height (mm) | 20.14 |
| Solid Height (Decimal Inch) | 0.7930 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.61 |
| Wire Size (Decimal Inch) | 0.0240 |
