Associated Spring Raymond - 3.05mm OD, 0.56mm Wire, 25.4mm Free Length, Compression Spring - 12.3 Lb Spring Rating, 11.52 N Max Work Load, Stainless Steel
Item #: 61421376
Brand: Associated Spring Raymond
Model #: C01200221000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 12.3000 |
| Maximum Work Load (N) | 11.52000046 |
| Solid Height (mm) | 15.24 |
| Solid Height (Decimal Inch) | 0.6000 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.56 |
| Wire Size (Decimal Inch) | 0.0220 |
