Associated Spring Raymond - 3.05mm OD, 0.56mm Wire, 28.45mm Free Length, Compression Spring - 13.7 Lb Spring Rating, 19.93 N Max Work Load, Music Wire
Item #: 61420899
Brand: Associated Spring Raymond
Model #: C01200221120M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 28.45 |
| Free Length (Decimal Inch) | 1.1200 |
| Spring Rate Pounds per Inch (Pounds) | 13.7000 |
| Maximum Work Load (N) | 19.93000031 |
| Solid Height (mm) | 16.94 |
| Solid Height (Decimal Inch) | 0.6670 |
| Material | Music Wire |
| Wire Size (mm) | 0.56 |
| Wire Size (Decimal Inch) | 0.0220 |
