Associated Spring Raymond - 3.05mm OD, 0.36mm Wire, 28.45mm Free Length, Compression Spring - 1.8 Lb Spring Rating, 3.2 N Max Work Load, Stainless Steel
Item #: 61420006
Brand: Associated Spring Raymond
Model #: C01200141120X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 28.45 |
| Free Length (Decimal Inch) | 1.1200 |
| Spring Rate Pounds per Inch (Pounds) | 1.8000 |
| Maximum Work Load (N) | 3.20000005 |
| Solid Height (mm) | 8.46 |
| Solid Height (Decimal Inch) | 0.3330 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.36 |
| Wire Size (Decimal Inch) | 0.0140 |
