Associated Spring Raymond - 2.24mm OD, 0.2mm Wire, 9.65mm Free Length, Compression Spring - 1.7 Lb Spring Rating, 1.69 N Max Work Load, Music Wire
Item #: 61418182
Brand: Associated Spring Raymond
Model #: C00880080380M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 2.24 |
| Outside Diameter (Decimal Inch) | 0.0880 |
| Free Length (mm) | 9.65 |
| Free Length (Decimal Inch) | 0.3800 |
| Spring Rate Pounds per Inch (Pounds) | 1.7000 |
| Maximum Work Load (N) | 1.69000006 |
| Solid Height (mm) | 2.13 |
| Solid Height (Decimal Inch) | 0.0840 |
| Material | Music Wire |
| Wire Size (mm) | 0.20 |
| Wire Size (Decimal Inch) | 0.0080 |
