Associated Spring Raymond - 1.45mm OD, 0.18mm Wire, 1/4" Free Length, Compression Spring - 2.6 Lb Spring Rating, 0.85 N Max Work Load, Stainless Steel
Item #: 61417739
Brand: Associated Spring Raymond
Model #: C00570070250X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 1.45 |
| Outside Diameter (Decimal Inch) | 0.0570 |
| Free Length (mm) | 6.35 |
| Free Length (Decimal Inch) | 1/4 |
| Spring Rate Pounds per Inch (Pounds) | 2.6000 |
| Maximum Work Load (N) | 0.85000002 |
| Solid Height (mm) | 2.26 |
| Solid Height (Decimal Inch) | 0.0890 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.18 |
| Wire Size (Decimal Inch) | 0.0070 |
