Associated Spring Raymond - 1.45mm OD, 0.15mm Wire, 7.87mm Free Length, Compression Spring - 1.3 Lb Spring Rating, 1.02 N Max Work Load, Music Wire
Item #: 61415782
Brand: Associated Spring Raymond
Model #: C00570060310M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 1.45 |
| Outside Diameter (Decimal Inch) | 0.0570 |
| Free Length (mm) | 7.87 |
| Free Length (Decimal Inch) | 0.3100 |
| Spring Rate Pounds per Inch (Pounds) | 1.3000 |
| Maximum Work Load (N) | 1.01999998 |
| Solid Height (mm) | 2.24 |
| Solid Height (Decimal Inch) | 0.0880 |
| Material | Music Wire |
| Wire Size (mm) | 0.15 |
| Wire Size (Decimal Inch) | 0.0060 |
