Associated Spring Raymond - 3.05mm OD, 0.46mm Wire, 1-1/4" Free Length, Compression Spring - 4.25 Lb Spring Rating, 7.07 N Max Work Load, Stainless Steel
Item #: 61415121
Brand: Associated Spring Raymond
Model #: C01200181250S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 31-3/4 |
| Free Length (Decimal Inch) | 1-1/4 |
| Spring Rate Pounds per Inch (Pounds) | 4.2500 |
| Maximum Work Load (N) | 7.07000017 |
| Solid Height (mm) | 14.20 |
| Solid Height (Decimal Inch) | 0.5590 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.46 |
| Wire Size (Decimal Inch) | 0.0180 |
