Associated Spring Raymond - 3.05mm OD, 0.51mm Wire, 20.57mm Free Length, Compression Spring - 10.16 Lb Spring Rating, 9.47 N Max Work Load, Stainless Steel
Item #: 61415063
Brand: Associated Spring Raymond
Model #: C01200200810S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 3.05 |
| Outside Diameter (Decimal Inch) | 0.1200 |
| Free Length (mm) | 20.57 |
| Free Length (Decimal Inch) | 0.8100 |
| Spring Rate Pounds per Inch (Pounds) | 10.1600 |
| Maximum Work Load (N) | 9.47000027 |
| Solid Height (mm) | 11.10 |
| Solid Height (Decimal Inch) | 0.4370 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.51 |
| Wire Size (Decimal Inch) | 0.0200 |
