Associated Spring Raymond - 4.57mm OD, 0.46mm Wire, 14.22mm Free Length, Compression Spring - 5.7 Lb Spring Rating, 7.83 N Max Work Load, Music Wire
Item #: 61414439
Brand: Associated Spring Raymond
Model #: C01800180560M
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 14.22 |
| Free Length (Decimal Inch) | 0.5600 |
| Spring Rate Pounds per Inch (Pounds) | 5.7000 |
| Maximum Work Load (N) | 7.82999992 |
| Solid Height (mm) | 4.11 |
| Solid Height (Decimal Inch) | 0.1620 |
| Material | Music Wire |
| Wire Size (mm) | 0.46 |
| Wire Size (Decimal Inch) | 0.0180 |
