Associated Spring Raymond - 4.57mm OD, 0.46mm Wire, 1-3/4" Free Length, Compression Spring - 1.8 Lb Spring Rating, 7.83 N Max Work Load, Music Wire
Item #: 61414389
Brand: Associated Spring Raymond
Model #: C01800181750M
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Type | Compression |
Outside Diameter (mm) | 4.57 |
Outside Diameter (Decimal Inch) | 0.1800 |
Free Length (mm) | 44.45 |
Free Length (Decimal Inch) | 1-3/4 |
Spring Rate Pounds per Inch (Pounds) | 1.8000 |
Maximum Work Load (N) | 7.82999992 |
Solid Height (mm) | 10.31 |
Solid Height (Decimal Inch) | 0.4060 |
Material | Music Wire |
Wire Size (mm) | 0.46 |
Wire Size (Decimal Inch) | 0.0180 |
