Associated Spring Raymond - 4.57mm OD, 0.51mm Wire, 25.4mm Free Length, Compression Spring - 3.8 Lb Spring Rating, 6.09 N Max Work Load, Stainless Steel
Item #: 61413878
Brand: Associated Spring Raymond
Model #: C01800201000X
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 25.40 |
| Free Length (Decimal Inch) | 1 |
| Spring Rate Pounds per Inch (Pounds) | 3.8000 |
| Maximum Work Load (N) | 6.09000015 |
| Solid Height (mm) | 7.67 |
| Solid Height (Decimal Inch) | 0.3020 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.51 |
| Wire Size (Decimal Inch) | 0.0200 |
