Associated Spring Raymond - 4.57mm OD, 0.9mm Wire, 15.75mm Free Length, Compression Spring - 64.31 Lb Spring Rating, 31.27 N Max Work Load, Stainless Steel
Item #: 61413449
Brand: Associated Spring Raymond
Model #: C01800350620S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Compression |
| Outside Diameter (mm) | 4.57 |
| Outside Diameter (Decimal Inch) | 0.1800 |
| Free Length (mm) | 15-3/4 |
| Free Length (Decimal Inch) | 0.6200 |
| Spring Rate Pounds per Inch (Pounds) | 64.3100 |
| Maximum Work Load (N) | 31.27000046 |
| Solid Height (mm) | 10.82 |
| Solid Height (Decimal Inch) | 0.4260 |
| Material | Stainless Steel |
| Wire Size (mm) | 0.89 |
| Wire Size (Decimal Inch) | 0.0350 |
