Associated Spring Raymond - 18.3mm OD, 1.14mm Wire, 3/4" Free Length, Cone Spring - 12.87 Lb Spring Rating, 37.76 N Max Work Load, Stainless Steel
Item #: 61396081
Brand: Associated Spring Raymond
Model #: A07200450500S
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Cone |
| Outside Diameter (mm) | 18.29 |
| Outside Diameter (Decimal Inch) | 0.7200 |
| Free Length (mm) | 19.05 |
| Free Length (Decimal Inch) | 3/4 |
| Spring Rate Pounds per Inch (Pounds) | 12.8700 |
| Maximum Work Load (N) | 37.75999832 |
| Material | Stainless Steel |
| Wire Size (mm) | 1.14 |
| Wire Size (Decimal Inch) | 0.0450 |
