KIPP - 5mm Body Length x 4mm Body Diam, 3 N Init to 7 N Final End Force, Thermoplastic Press-Fit Ball Plungers - 0.7mm Max Ball Reach, 1mm Flange Thickness
Item #: 59176099
Brand: KIPP
Model #: K0334.04
Exact Tooling IR#: 04
Product Specifications | |
---|---|
Body Diameter (mm) | 4.00 |
Body Length (Decimal Inch) | 0.1969 |
Body Length (mm) | 5.00 |
Body Material | Thermoplastic |
Ball Material | Stainless Steel |
Maximum Ball Reach (mm) | 0.70 |
Maximum Ball Reach (Decimal Inch) | 0.0276 |
Initial End Force (N) | 3.00 |
Initial End Force (Lb.) | 0.67 |
Final End Force (N) | 7.00 |
Final End Force (Lb.) | 1.57 |
Length Under Flange (mm) | 4.00 |
Flange Diameter (mm) | 4.60 |
Flange Thickness (mm) | 1.00 |
