Vargus - TMSD, Internal or External, Right Hand, 1.772" Max Depth of Cut, 0.98 to 1.77" Groove Width, Indexable Grooving Tool Holder - 9V Insert Compatibility, 7/16" Shank Height, 7/16" Shank Width, 4.921" OAL, Through Coolant
Item #: 58956145
Brand: Vargus
Model #: 67143
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | Internal or External |
| Toolholder Type | Face Grooving |
| Hand of Holder | Right Hand |
| Maximum Depth of Cut (Decimal Inch) | 1.7720 |
| Minimum Groove Width (Decimal Inch) | 0.9800 |
| Maximum Groove Width (Decimal Inch) | 1.7700 |
| Overall Length (Decimal Inch) | 4.9210 |
| Toolholder Style | TMSD |
| Insert Compatibility | 9V |
| Shank Height (Inch) | 7/16 |
| Shank Width/Diameter (Inch) | 7/16 |
| Series | CGMC |
| Through Coolant | Coolant Through |
| Through Coolant | Coolant Through |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Number of Inserts Used on Toolholder | 1 |
| Manufacturers Catalog Number | CGMC 7/16C17-45-9-3 |
