KIPP - 17/32" Body Length x 10mm Body Diam, 10 N Init to 20 N Final End Force, Stainless Steel Press-Fit Ball Plungers - 2.7mm Max Ball Reach, 2.5mm Flange Thickness
Item #: 58624651
Brand: KIPP
Model #: K0333.10
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Body Diameter (mm) | 10.00 |
| Body Length (Decimal Inch) | 0.5315 |
| Body Length (mm) | 13.50 |
| Body Material | Stainless Steel |
| Ball Material | Stainless Steel |
| Maximum Ball Reach (mm) | 2.70 |
| Maximum Ball Reach (Decimal Inch) | 0.1063 |
| Initial End Force (N) | 10.00 |
| Initial End Force (Lb.) | 2.25 |
| Final End Force (N) | 20.00 |
| Final End Force (Lb.) | 4.50 |
| Length Under Flange (mm) | 11.00 |
| Flange Diameter (mm) | 12.00 |
| Flange Thickness (mm) | 2.50 |
