Brand: Walker Magnetics / Part #: NEO-2000
Item #: 17319005
Brand: Walker Magnetics
Model #: NEO-2000
Product Specifications
| Magnet Type | Rare Earth |
| Magnet Activation | Locking On/Off Handle |
| Height (Decimal Inch) | 10.700000 |
| Load Capacity Flat Objects (Lb.) | 4400.00 |
| Load Capacity Round Objects (RoundObjects) | 2200.0 |
| Material Orientation | Horizontal |
| Permanent | Yes |
| Maximum Working Temperature | 180 |
| Body Material | Steel |
| Bail Opening Height | 3.63 in |
| Bail Opening Width | 2.52 in |
| Number Of Poles | 2 |
| Features | Handle Locks in Both On and Off Positions; Lift Flat and Round Loads; Heat-Resistant Up to 180? (82?C); ASME B30.20 BTH-1 Design Category B Service Class 3; On/Off Rare Earth Permanent Magnet; 3:1 Design Factor |
| Standards | ASME B30.20 BTH-1 Design Category B Service Class 4 |
| Load Capacity (Lb. - 3 Decimals) | 4400.000 |
| Width (Decimal Inch - 4 Decimals) | 6.5000 |
| Length (Decimal Inch - 4 Decimals) | 18.8000 |
