TE-CO - Press-Fit Ball Plungers Body Diameter (Decimal Inch): 0.2500 Body Length (Decimal Inch): 0.5240
Item #: 00579292
Brand: TE-CO
Model #: 53702
Product Specifications
Press-Fit Ball Plungers; Body Diameter (Decimal Inch): 0.2500 ; Body Length (Decimal Inch): 0.5240 ; Body Material: Steel ; Ball Material: Stainless Steel ; Flange: Yes ; Maximum Ball Reach (Decimal Inch): 0.0700
| Body Diameter (Decimal Inch) | 0.2500 |
| Body Length (Decimal Inch) | 0.5240 |
| Body Material | Steel |
| Ball Material | Stainless Steel |
| Flange | Yes |
| Maximum Ball Reach (Decimal Inch) | 0.0700 |
| Initial End Force (Lb.) | 1.50 |
| Final End Force (Lb.) | 3.50 |
| Length Under Flange (Decimal Inch) | 0.4800 |
| Flange Diameter (Decimal Inch) | 0.3120 |
| Flange Thickness (Decimal Inch) | 0.0440 |
| Ball Diameter (Decimal Inch) | 0.1880 |
| Finish/Coating | Black Oxide |
| Tolerance (Decimal Inch) | +0.0020 |
| Locking Element | No |
