De-Sta-Co - 375 Lb Inner Hold Capacity, Horiz Mount, Air Power Hold-Down Toggle Clamp - G1/8 Port, 145 Max psi, 103° Bar Opening, 35.05mm Height Under Bar
Item #: 57186983
Brand: De-Sta-Co
Model #: 807-UE
Exact Tooling IR#: 04
Features and Benefits
Horizontal mounts indicate that the cylinder is mounted parallel to the clamping bar's closed position.
| Product Specifications | |
|---|---|
| Power Type | Pneumatic |
| Mounting Orientation | Horizontal |
| Holding Capacity - Inner (N) | 1670 |
| Holding Capacity - Inner (Lb.) | 375 |
| Height Under Bar (mm) | 35.05 |
| Height Under Bar (Decimal Inch) | 1.38 |
| Port Size | G1/8 |
| Bar Opening (Degrees) | 103 |
| Length Distance Between Mount Holes (mm) | 19.05 |
| Length Distance Between Mount Holes (Decimal Inch) | 0.7500 |
| Width Distance Between Mount Holes (mm) | 31.75 |
| Width Distance Between Mount Holes (Decimal Inch) | 1.2500 |
| Clamping Force - Inner (N) | 2573 |
| Clamping Force - Inner (Lb.) | 578 |
| Bar Extension (Decimal Inch) | 2.5100 |
| Bar Extension (mm) | 63.75 |
| Overall Open Length (mm) | 236.98 |
| Overall Open Length (Decimal Inch) | 9.33 |
| Overall Closed Length (mm) | 173.23 |
| Overall Closed Length (Decimal Inch) | 6.82 |
| Overall Open Height (Decimal Inch) | 5.83 |
| Overall Open Height (mm) | 148.08 |
| Overall Closed Height (mm) | 76.20 |
| Overall Closed Height (Decimal Inch) | 3.00 |
| Outer Clamping Force (N) | 1327 |
| Outer Clamping Force (Lb.) | 298 |
| Maximum Air Pressure (psig) | 145.00 |
| Maximum Air Pressure (bar) | 10.00 |
| Mounting Hole Size (mm) | 7.11 |
| Mounting Hole Size (Decimal Inch) | 0.2800 |
| Bar Style | Solid |
| Bar End Type | Closed |
| Maximum Mechanical Advantage | 3.3:1; 6.4:1 |
| Sensor Compatibility | Round; T-Slot |
| Cylinder Bore Size (mm) | 32.00 |
| Cylinder Bore Size (Decimal Inch) | 1.2600 |
| Spindle Thread Size | M8 |
| Maximum Operating Temperature (C) | 90.00 |
| Maximum Operating Temperature (F) | 194.00 |
| Minimum Operating Temperature (F) | 14.00 |
| Minimum Operating Temperature (C) | -10.00 |
| Includes | Spindle Assembly |
