Schneider Electric - 6 Amp, 240/415 VAC, 1 Pole, DIN Rail Mounted Miniature Circuit Breaker - Magnetic Trip, 10 kA at 240 VAC Breaking Capacity, 18-4 AWG, 76mm Deep x 81mm High x 18mm Wide
Item #: 56787773
Brand: Schneider Electric
Model #: 24049
Exact Tooling IR#: 04
Features and Benefits
Magnetic tripping mechanisms are designed with a solenoid (electromagnet), which will quickly disconnect in case of a short circuit or overload. They are not greatly affected by extreme environmental conditions, but are sensitive to low-overloads.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Miniature Circuit Breaker |
| Amperage | 6 |
| Number of Poles | 1 |
| Breaking Capacity | 10 kA @ 240 VAC |
| Tripping Mechanism | Magnetic |
| Terminal Connection Type | Box Lugs |
| Mounting Type | DIN Rail Mounted |
| Voltage | 240/415 VAC |
| Wire Size (sq mm) | 1-25 |
| Wire Size (AWG) | 18-4 |
| Durability | 10000 Cycles |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -22 |
| Overall Depth (Decimal Inch) | 3 |
| Overall Depth (mm) | 76 |
| Overall Height (mm) | 81 |
| Overall Height (Decimal Inch) | 3.1900 |
| Overall Width (mm) | 18 |
| Overall Width (Decimal Inch) | 0.7100 |
| Standards Met | CE Marked; CSA C22.2 No. 5.1 Circuit Breakers: File No. 179014; IEC 60947-2; UL 489 Circuit Breakers: File No. E215117; UL Listed for SWD Applications |
| Reset Actuator Type | Automatic |
