Square D - 60 Amp, 600 VAC, 3 Pole Nonfused Safety Switch - NEMA 4, 4X & 5, 1 & 3 Phase, 30 hp at 600 VAC (Single Phase), 60 hp at 600 VAC (Triple Phase)
Item #: 56771843
Brand: Square D
Model #: HU362NSS
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| NEMA Enclosure Rating | 4; 4X; 5 |
| Fused | NonFused |
| Number of Poles | 3 |
| Amperage | 60 |
| Voltage | 600 VAC |
| Horsepower at 1 Phase | 30 @ 600 VAC |
| Horsepower at 3 Phase | 60 @ 600 VAC |
| Number of Phases | 1; 3 |
| Number of Wires | 3 |
| Overall Height (mm) | 451 |
| Overall Height (Decimal Inch) | 17-3/4 |
| Overall Width (mm) | 229 |
| Overall Width (Decimal Inch) | 9 |
| Overall Depth (Decimal Inch) | 6.3800 |
| Overall Depth (mm) | 162 |
| Standards Met | Federal Specifications WS-865c; NEMA KS1; UL 98; UL Listed File No. E154828; UL Listed File No. E2875 |
