Square D - 30 Amp, 600 VAC, 3 Pole Fused Safety Switch - NEMA 4, 4X & 5, 3 Phase, 7.5 hp at 480 VAC (Single Phase), 20 hp at 600 VAC (Triple Phase)
Item #: 56753981
Brand: Square D
Model #: H361SSEI
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| NEMA Enclosure Rating | 4; 4X; 5 |
| Fused | Fused |
| Number of Poles | 3 |
| Amperage | 30 |
| Voltage | 600 VAC |
| Horsepower at 1 Phase | 7.5 @ 480 VAC |
| Horsepower at 3 Phase | 20 @ 600 VAC |
| Number of Phases | 3 |
| Material | Stainless Steel |
| Overall Height (mm) | 371 |
| Overall Height (Decimal Inch) | 14.6000 |
| Overall Width (mm) | 165 |
| Overall Width (Decimal Inch) | 6-1/2 |
| Overall Depth (Decimal Inch) | 4.8800 |
| Overall Depth (mm) | 124 |
| Standards Met | Federal Specifications WS-865c; NEMA KS1; UL 98; UL Listed File No. E154828; UL Listed File No. E2875 |
