Square D - 250 Amp, 250 VDC, 600 VAC, 3 Pole, Unit Mount Molded Case Circuit Breaker - Thermal Magnetic Trip, 18 kA at 600 VAC Breaking Capacity, 3/0 (Aluminum) AWG, 127mm Deep x 191mm High x 95.1mm Wide
Item #: 56749450
Brand: Square D
Model #: JGL36250AA
Exact Tooling IR#: 04
Features and Benefits
MCCB (Molded Case Circuit Breakers) are designed to protect against overloads and short circuits in both low and high power applications. Trip settings are adjustable and they are thermal and thermal-magnetically operated. The current rating is up to 2,500 amperes.
Thermal-magnetic tripping mechanisms are designed with both a bi-metal switch and an electromagnet. They perform as a thermal breaker for low level overloads and perform as a magnetic breaker for instantaneous tripping mechanism at high levels.
| Product Specifications | |
|---|---|
| Circuit Breaker Type | Molded Case Circuit Breaker |
| Amperage | 250 |
| Number of Poles | 3 |
| Breaking Capacity | 18 kA @ 600 VAC |
| Tripping Mechanism | Thermal-Magnetic |
| Terminal Connection Type | Lug |
| Mounting Type | Unit Mount |
| Voltage | 250 VDC; 600 VAC |
| Wire Size (AWG) | 3/0 (Aluminum) |
| Maximum Operating Temperature (F) | 158 |
| Minimum Operating Temperature (F) | -13 |
| Overall Depth (Decimal Inch) | 5 |
| Overall Depth (mm) | 127 |
| Overall Height (mm) | 191 |
| Overall Height (Decimal Inch) | 7.5200 |
| Overall Width (mm) | 95.10 |
| Overall Width (Decimal Inch) | 3.7400 |
| Standards Met | CCC; CSA Certified; Federal Specification W-C 375 b/Gen; HACR; UL Listed |
| Reset Actuator Type | Toggle Switch |
