Sandvik Coromant - 881020204 53 Grade 2044 Carbide Indexable Drill Insert - TiAlN/AlCr2O3 Finish, Square
Item #: 54955331
Brand: Sandvik Coromant
Model #: 5962708
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | 881 |
| Insert Size | 020204 |
| Material | Carbide |
| Manufacturer's Grade | 2044 |
| Thickness (mm) | 2.38 |
| Thickness (Decimal Inch) | 0.0937 |
| Corner Radius (mm) | 0.40 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Shape | Square |
| Hole Diameter (mm) | 2.50 |
| Hole Diameter (Decimal Inch) | 0.0984 |
| Relief Angle | 7 |
| Coating | TiAlN/AlCr2O3 |
| Coating Process | PVD |
| Cutting Direction | Right Hand |
| Chipbreaker | 53 |
