KIPP - 1/4-20, 3.5mm Ball Diam, 14mm Body Length, 1mm Max Ball Reach, Threaded Ball Plunger - Stainless Steel Body, Stainless Steel Ball, 9 N Initial End Force, 13 N Final End Force
Item #: 54627914
Brand: KIPP
Model #: K0310.A2
Exact Tooling IR#: 04
Features and Benefits
Stainless steel is a strong, corrosion-resistant alloy with excellent resistance to heat. It is used in high-stress, outdoor and corrosive applications.
Stainless steel balls are ideal for food, medical and industries where resistance from contamination is required. They are also rust and corrosion and resistant.
| Product Specifications | |
|---|---|
| Thread Size | 1/4-20 |
| Body Length (mm) | 14.00 |
| Body Length (Decimal Inch) | 0.5512 |
| Body Material | Stainless Steel |
| Ball Material | Stainless Steel |
| Initial End Force (N) | 9.00 |
| Final End Force (N) | 13.00 |
| Locking Element | No |
| Ball Diameter (Decimal Inch) | 0.1378 |
| Ball Diameter (mm) | 3.50 |
| Finish/Coating | Natural |
| Installation Type | Slotted |
| Maximum Ball Reach (mm) | 1.00 |
| Maximum Ball Reach (Decimal Inch) | 0.0394 |
