KIPP - 1/4-28, 3.5mm Ball Diam, 15mm Body Length, 1mm Max Ball Reach, Threaded Ball Plunger - Steel Body, Steel Ball, 9 N Initial End Force, 13 N Final End Force
Item #: 54622097
Brand: KIPP
Model #: K0315.AJ
Exact Tooling IR#: 04
Features and Benefits
Steel is strong and durable but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
Steel balls are strong and durable, but less corrosion resistant than stainless steel. To improve its resistance to corrosion, it may receive additional finishes and coatings.
| Product Specifications | |
|---|---|
| Thread Size | 1/4-28 |
| Body Length (mm) | 15.00 |
| Body Length (Decimal Inch) | 0.5906 |
| Body Material | Steel |
| Ball Material | Steel |
| Initial End Force (N) | 9.00 |
| Final End Force (N) | 13.00 |
| Locking Element | No |
| Ball Diameter (Decimal Inch) | 0.1378 |
| Ball Diameter (mm) | 3.50 |
| Finish/Coating | Black Oxide |
| Installation Type | Hexagon Socket |
| Maximum Ball Reach (mm) | 1.00 |
| Maximum Ball Reach (Decimal Inch) | 0.0394 |
